MGS-450 CO2 controller unit with buzzer and relay output - Standalone CO2 detector

On quotation
SKU
MGS-CO2
Product on quotation onlyDevis

The MGS-450 CO2 controller unit is an autonomous gas detector with integrated buzzer and relay outputs for local control systems. A linear 4-20 mA measurement output is also available for connection to a central controller unit or supervision.

Thanks to the MGS-400 application (compatible with Android and iOS), the use of this autonomous gas detection unit is simple and intuitive and particularly suitable in the winemaking sector during alcoholic fermentation, devatting or tank cleaning. Detailed description

Documentation
Available options
Select your configuration and/or options, then add the product to your cart.
* Required option
Total amount of your selection:
$0.00
Available options
Select your configuration and/or options, then add the product to your cart.
* Required option
Total amount of your selection:
$0.00

The MGS-450 single-point CO2 controller

With a high protection index (IP66), the MGS-450 CO2 controller, is waterproof and dustproof, and is particularly well suited for wine cellars, in craft or industrial breweries and all applications requiring control of carbon dioxide in ambient air.

MGS-408 multipoint CO2 controller

For tertiary or industrial applications requiring several measurement points, the MGS-408 gas controller unit can control up to 8 MGS-410 CO2 detectors connected in series on a single line thus considerably reducing wiring costs.

The digital display as well as a group of LEDs provide a real-time view of the concentration and status of each CO2 sensor and an intuitive menu allows easy configuration of the controller unit which keeps the gas alarm history on an SD card. Three freely assignable alarm relays are available for servo controls.

The MGS-400 smartphone app

Thanks to the MGS-400 application (compatible with Android and iOS), users can intuitively use, commission and maintain their gas detection system without training or specialized tools.

The MGS-400 smartphone app allows users to perform a variety of functions to configure and interact with the MGS-400 series gas detectors, including:

  • Real time measurements display
  • Device configuration
  • Device calibrations / tests
  • Generate customizable calibration certificates

MGS CO2 controllers technical specifications

MGS-450 single-point CO2 controller

  • Sensor: Infrared 0-5000 ppm or 0-5% / vol.
  • Power supply: 24 Vac / Vdc (auto select).
  • Integrated audiovisual alarm:
    - Status indicator with three-color LED
    - Integrated buzzer 72 dB (A) at 10 cm
  • Outputs:
    - Linear analog output 4-20 mA
    - Modbus RTU digital communication
    - 3 configurable SPDT relays
  • Configuration: Via the MGS-400 application and Bluetooth connection
  • Dimensions: 165 x 165 x 87 mm
  • Protection index: IP66

MGS-408 multipoint CO2 controllers

  • MGS-408 controller unit:
    - Power supply: 100-240 Vac
    - Capacity: Up to 8 MGS-410 or MGS-450 detectors
    - Wiring: Modbus digital wiring (2 twisted pairs)
    - Display: Backlit graphic LCD
    - Status control by LED (green, orange, red) Alarm: 3 alarm relays for the servos
    - Data recording: Recording of events on SD card
    - Certifications: CE, UL / CSA / IEC EN 61010-1
  • MGS-410 CO2 transmitter:
    - Sensor: Infrared 0-5000 ppm or 0-5% / vol.
    - Power supply: 24 Vac / Vdc (auto select).
    - Outputs: Modbus RTU digital communication
    - Configuration: Via the MGS-400 application and Bluetooth connection
    - Dimensions: 130 x 130 x 68 mm
    - Protection index: IP66
