Combustible gas detector - X-am EXPLO Explosive gas detector

Starting at $401.20
SKU
Xam_EXPLO

The Dräger X-am EXPLO is an ATEX combustible gas detector, for the detection of explosive gases. It detects natural gas, butane, propane, hydrocarbons, solvents and alcohols.

An external sampling pump can be added to the combustible gas detector, which then constitutes the ideal solution for measurements to authorize the entry of tanks and wells or for the search for combustible gas leaks. Detailed description

Documentation
Available options
Select your configuration and/or options, then add the product to your cart.
* Required option
Total amount of your selection:
$0.00
Available options
Select your configuration and/or options, then add the product to your cart.
* Required option
Total amount of your selection:
$0.00

The X-am EXPLO, a combustible gas detector for all situations

The Dräger X-am EXPLO has ATEX approval for zone 0 and therefore offers very high safety in areas subject to explosion hazards. The innovative Ex catalytic sensor impresses with its excellent poison resistance from silicone and hydrogen sulfide. Associated with a high drift stability, this allows the sensor to benefit from an exceptional over 4 years lifespan.

Light and ergonomic, the X-am EXPLO combustible gas detector is particularly ideal for industrial environments. The device is protected against water and dust in compliance with the IP 67 protection class, which allows it to preserve all of its functionality even after falling into water.It offers high comfort thanks to its low weight and ergonomic design. An integrated rubber protection and shock-resistant sensors provide reinforced safety.

An optional external pump with a hose up to 30 meters long is an ideal solution for remote sample measurements in tanks or pits or to detect leaks. The pump automatically starts upon combustible gas detector start-up. The switch from diffusion to pump operation can be handled quickly and easily without any tool.

The Dräger combustible gas detector technical specifications

  • Measuring range: 0 to 100 % LEL in 1 % increments
  • Optional sensors: O2, CO or H2S
  • Alarms: 360° ultra-bright indicators, 90 db sounder at 30cm, vibrating alarm
  • Dimensions (L x H x P): 48 x 130 x 44 mm / Weight: around 250 g
  • Protection class: IP 67
  • Datalogger: Data retrievable using an infrared interface > 1000h
  • Battery life: 12 hours (with NiMH battery) Charging time 4 hours
  • Electromagnetic interference/radio interferance : Compliant with the 2004-108-CE electromagnetic compatibility directive
  • Certifications: ATEX / IECEx, CSA (Canada & USA) & MED Marine
  • Equipement Directive 96/98/CE – CE Marked
  • Warranty: 3 years



Gas LEL: Lower Explosive Limit
Acetone 2,5 % of volume
Acetylene 2,5 % of volume
Ammonia 15,0 % of volume
Benzene 1,2 % of volume
Butane 1,9% of volume
Butanol (Butyl alcohol) 1,4 % of volume
Diethyl ether 1,9% of volume
Ethane 3,0 % of volume
Ethanol (Ethyl alcohol) 3,3 % of volume
Ethylène 2,7 % of volume
Hexane 1,1 % of volume
Hydrogen 4,0 % of volume
Isopropanol (Isopropylic alcohol) 2,0 % of volume
Methane 5,0 % of volume
Methanol (Methyl alcohol) 6,0 % of volume
Methyl ethyl ketone 1,4 % of volume
Carbon monoxide 12,5 % of volume
n-Pentane 1,4 % of volume
Ethylene oxide 2,7 % of volume
Propane 2,1 % of volume
Propylene 2,0 % of volume
Styrene 0,9 % of volume
Toluene 1,1 % of volume
Xylene 1,1 % of volume
