Area gas monitor - X-zone 5500
The Dräger X-zone 5500 area gas monitor is a little different from conventional gas detection beacons. It is an innovative and powerful concept disigned for safety that integrates a portable gas detector into the area gas monitor to form a unique and flexible gas detection system.
Easy to transport, robust and water and dust proof, the Dräger X-zone 5500, combined with the Dräger X-am 5000, 5100 or 5600 portable gas detectors can measure up to six gases simultaneously. Detailed description
The Dräger X-zone area gas monitor assets
Innovative area surveillance
The Dräger X-zone 5500 can be used in combination with the X-am 5000, X-am 5100 or X-am 5600 portable gas detectors and can monitor from 1 to 6 gases. It is an innovative and powerful device that integrates a portable gas detector into the area gas monitor to form a unique and flexible system.
Up to 120 hours of continuous runtime
The 24 Ah battery of the X-zone 5500 offers high continuous operation that can last up to 120 hours. This is equivalent to a complete work week. This is a significant advantage for construction sites that start on Monday morning and finish on Friday afternoon: no interruption in gas monitoring due to the battery charge.
Clear and distinct alarms
A green LED light ring indicates that the environment is safe and free from toxic or combustible gas. When gas or dangerous substances are detected, the LED ring becomes red, providing a visual warning that efficiently indicates dangerous gas presence. At the same time, a high level audible alarm sounds.
A wireless network of interconnected monitors
Up to 25 area gas monitors can be automatically interconnected to create a wireless gas alert system. This connectivity of the monitoring devices allows efficient and fast protection on large zones. If one of the monitors detects gas, it will transmit the signal to all the connected devices. A red master signal blinks on the monitor that detected the gas, in contrast with the other connected devices blinking red and green, thus allowing easy identification of the dangerous area.
Dräger X-zone 5500 technical specifications
Dimensions (l x h x p):490 x 300 x 300 mm
Weight: 10 kg (battery 24 Ah)
- Max. temperature +50 °C
- Pressure 700 to 1 300 hPa
- Humidity 10 à 95 % HR
Ingress protection :IP 67
- 360° LED (light ring)
- 360° audible alarm, 120 dB at a 30 cm distance
- Configurable alarms: profile, frequency & volumes
Operating signal: Status light (360°), light ring (LED)
Autonomy: Approx. 120 hours (24 Ah battery) depending on installed sensors and status light configuration
Charge time: Approx. 14 h
Flexible power source: external battery charger 100 – 240 V (universal) or wireless induction charger
Pump operation: hose maximum length: 45 m, 30 m for zone 0
Alarm output: Dry contact for intrinsically safe electric circuit (6 poles); < 20 V to 0,25 A (0,15 A constant current)
- ATEX : I M1 Ex ia I Ma ; II 1G Ex ia IIC T3 Ga ; II 2G Ex ia d IIC T4 Gb
- IECEx : Ex ia IIC T3 Ga ; Ex ia d IIC T4 Gb ; Ex ia I Ma
- CSA/US : Classe I, zone 0, A/Ex ia IIC T3/Ga ; Classe I, zone 1, A/Exia d IIC T4/Gb)
